All series adopting pump from Germany。
Constant temperature of test roll，magnesium die－casting equipment，extruder equipment， the equipment require higher temperature。
Minimum space easy to operation maintenance。
The control box and the temperature controller are separated， so that be able to extend the useful duration of electric part。
Economize the primary invest ment cost for large capacity boiler。
Seamless tube for heater and cooler，long life time and hight efficiency。
Adopting imported parts from French and Japan，with longer terms of service。
MODEL
JSO-3015
JSO-4030 ( Single Cycle )
JSO-4030 ( Two-cycle )
POWER SUPPLY
AC220~440V 50/60HZ
MAXIMUM WORKING TEMP
300℃
ACCURACY OF TEMP CONTROL
± 1℃
MEDIUM HEAT TRANSMISSION
OIL
MINMUM WORKING TEMP
SUPPLY WATER TEMP + 50℃
COOLING METHOD
INDIRECT COOLING
HEATING CAPACITY
12KW
20KW
20KW+20KW
WATER SUPPLY PRESSURE
1kg More
PUMP POWER
1.5HP
4HP
4HP+4HP
OIL TANK CAPACITY
16L
32L
MAX POWER CONSUMPTION
13.1KW
23KW(Optional)
23KW+23KW(Optional)
COOLING CAPACITY
15000Kcal/H/300℃
18000Kcal/H/300℃
PUMP MAX FLOW PRESSURE
60HZ
60L/min 6.5kg/c㎡
100L/min 13kg/c㎡
COOLING WATER PIPE
1/2" PT
3/4" PT
HOT OIL PIPEING
2 INLET 2 OUTLET 3／8〞PT OR 1 INLET 1 OUTLET 1〞PT
HOT OIL DRAIN PIPE
3/8" PT
L×W×H(CM)
70×40×75
WEIGHT(Kg)
75
110
200
◆SPECIAL DESIGN UPON REQUEST。 ◆ANY NEW MODIFIED SPECIFICATIONS SHOULD BE REFERRED TO EXISTING MACHINES。
